| Brand Name: | NUOYINGJIAYE |
| Model Number: | NYRD808 |
| MOQ: | 1 pcs |
| Price: | $450 to $1700 /pcs |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 pcs/ pre month |
Technical parameter
| Application | All kinds of liquids (strong corrosion, low dielectric constant, stirring, steam, crystallization, condensation, slurry, high temperature and high pressure, etc.) |
| All kinds of dust (strong dust, floating dust, cement powder, lime powder, fly ash, crystallization and other occasions) | |
| Various solids (grain, small stones, iron ore, coal, etc.) | |
| Item number | NYRD805,NYRD806,NYRD807,NYRD808,NYRD809,NYRD810,NYRD86 |
| NYRD87,NYRD-PB,NYRD-SD,NYRD-TJ,NYRD- SL | |
| Antenna form | Bar type, water drop type, plate type, horn type, surface type, lens type |
| The antenna material | PTFE,304,316,PP,PFA |
| Measuring range | 10m,20m,30m,35m,40m,80m |
| Accuracy of measurement | 0.05%~0.1%F.S |
| Power supply | 24VDC(two wire,four wire),220VAC |
| Signal output | 4-20mA/HART/RS485/Modbus... |
| The process temperature | -40~+130℃,-40~+150℃,-40~+2600℃,-40~+1200℃ |
| Process pressure | -0.1~0.3Mpa,-0.1~2.0Mpa,-0.1~4.0Mpa, |
| Process connection | Thread, bracket, flange,Health clamp (optional) |
| Electrical interface | M20x1.5,1/2”NPT |
| Protection grade | IP65,IP67,IP68(optional) |
| Explosion-proof grade | ExiaIICT6 Ga,ExdIICT6 Gb(As shown in the certificate) |
